Maxso Air Motor 20K Midwest 4-Hole Connection M20A-NS/M4 - Beyes Dental


Maxso Air Motor 20K Midwest 4-Hole Connection M20A-NS/M4 - Beyes Dental

SKU : 210-MT2010


The M20A Motor offers efficient, powerful and constant torque with operational speeds up to 20,000 RPM. Its innovative fluid dynamics generate about twice as much torque compared to a conventional low speed motor in the 5,000–10,000 RPM range. The M20A Motor is comfortable to operate - it is lightweight, perfectly balanced and delivers smooth power control.

Warranty - 12 Months

4th Quarter Promotion (ends 12.31.24)

Buy 2 Maxso Air Motors, Get 1 FREE

Show More
Log in see to prices

Manufacturer: Beyes Dental

SKU: 210-MT2010

Maxso Air Motor 20K Midwest 4-Hole Connection M20A-NS/M4 - Beyes Dental

The M20A Motor offers efficient, powerful and constant torque with operational speeds up to 20,000 RPM. Its innovative fluid dynamics generate about twice as much torque compared to a conventional low speed motor in the 5,000–10,000 RPM range. The M20A Motor is comfortable to operate - it is lightweight, perfectly balanced and delivers smooth power control.

  • Powerful torque even at a low speed
  • Long working life
  • Perfectly balanced, lightweight design
  • Forward/reverse drive with continuous speed control
  • Safe and easy double-lock connection
  • Autoclavable for complete infection control
  • Compatible with all standard ISO-type attachments
Maximum speed 5,000 rpm – 20,000 rpm
Air Pressure Range 0.2-0.3 MPa
Exhaust Pressures Recommended 0.07 MPa, max. *0.25 MPa
Recommended Air Pressure Range 0.25 MPa
Water Pressure Range 0.05-0.2 MPa
Usage Speed Range 5,000-20,000 rpm
Air Flow (At 0.25MPa) 46 NL/min
Stop Torque (At 0.25MPa) 3.5 N cm
